How to Use an Electrical Pump to Make Homebrewing Easier

IMG_20150111_144629278

Because I like beer, I have over the years dabbled in trying to make it. At no point have I had much success. My first attempt came in college, where not having control over the temperature of the dorm, as it turns out, is a problem. Attempts to artificially create the correct temperature with a cracked window in winter led to two cases of frozen beer and very small glass shards everywhere. Subsequent efforts first in Maine and then in Denver were less destructive but best described as not provably toxic.

My willingness and ability to improve, however, was always limited by the soul-killing tedium of bottling. Each time I’d brew a batch, I’d remember why it had been so long since the last time: I absolutely hate bottling. It wasn’t until a conversation with Devin a month or two ago that I remembered that, as the owner of a kegerator, I had an option other than bottling: kegging.

Hence last weekend’s brew day:

The good news is that kegging is substantially lower effort than bottling. The bad news is that it comes with some additional costs in terms of maintenance. To assist with these as well as the brewing process itself, I decided to invest in an electrical pump. Here’s how we use it.

The Basics

Are not very complicated. The basic idea is to use an electrical pump wherever moving water is required, whether for cleaning, cooling or both. After looking around, and one aborted selection of a non-submersible utility pump, with the assistance of homebrewtalk.com user @Mike_kever_kombi I settled on a Flotec 1/6 HP submersible utility pump, model # FP0S1300X. It’s available for $83.28 at Home Depot, which was considerably cheaper than the base ~$165 price I’d seen quoted for wort chilling pumps.

There aren’t too many rules associated with the pump; basically you drop it in, turn it on and it pumps water. But obviously be careful because you’re dealing with electricty and water, never a great combination. Besides the safety concerns, pay attention to the hose diameters on both sides. In my experience, the pump will not operate with 5/16″ tubing – common to many wort chillers – but is fine with slightly larger 3/8″ lines, in spite of what the user manual claims. It’s also critically important not to run the pump dry; pay very close attention, in other words, if you’re doing something other than recirculating water.

Other than that, it’s pretty straightforward. On to the specifics of how we use it.

Wort Chilling

2015-01-11 14.42.56

Whenever I’ve used our copper wort chiller in the past, I’ve always plugged it into a standard garden hose spigot and used your basic cold tap water to bring down the temperature of the wort after a boil. In Maine, in the winter, this is less practical, particularly during brew days like ours where the outside temperature is twenty degrees below freezing. Which is where the pump comes in.

In order to chill the wort, I take a piece of 3/8″ line and connect a standard garden hose connection (see above) to one end, hose clamp it, and clamp the other end to input of the wort chiller. A second 3/8″ line, meanwhile, is clamped to the output. The standard garden hose connection is then attached to the Flotec pump, and pump and output line from the chiller are both added to a six gallon bucket filled with cold water and a ten pound bag of ice.

Fifteen minutes or so before then end of your boil, you add the chiller to your brew kettle to sanitize it as usual. When it’s time to chill the wort, then, you merely plug the pump in. More or less instantly the ice cold water will be pumped into the chiller, which absorbs the heat and recirculates the heated waste water back into the bucket full of ice water. As a closed system, there’s not much to worry about here, and it works very well. We cooled our boiled wort down to the pitch temp in less than twenty minutes thanks to the pump.

When you’re done, simply unhook the garden hose connection, drain the pump, and you’re ready to use it for cleaning.

Kegerator or Jockey Box Cleaning

In addition to using the pump to chill wort, it’s highly useful in cleaning the lines of whatever you’re using to serve your kegs. Basically, I do this in three stages. The idea is to clean the lines, rinse them, then rinse them again.

IMG_20150111_144835256

  1. Detergent Clean: Mix 4 tablespoons with 2 gallons hot water in five gallon bucket (~$3 at Home Depot), recirculate (input and output lines both in the same bucket) through lines for 3-5 minutes. When complete, dump mixture and drain pump.
  2. Recirculating Rinse: In empty bucket, add two gallons of hot clean water. Recirculate this through the lines for 3-5 minutes. When complete, dump mixture and drain pump.
  3. Cleansing Rinse: In empty bucket, add one gallon hot clean water. Pump through lines outputting to sink or other drain until complete, watching carefully not to allow pump to run dry.

What You Need

IMG_20150111_144226363

To make all of the above work, you’ll need a different connector depending on what you’re cleaning. One end of your input line should keep the garden hose connection mentioned above to connect to the pump. If you’re cleaning a jockey box, then, you’ll simply need a 3/8″ barb (middle above) along with a standard 7/8″ hex nut coupler (left above) – the same one you use for keg couplers. Attach and clamp this to your hose, then screw it on to the back of your jockey box as if it was a beer input line.

If you’re cleaning kegerator lines, it may or may not be the same setup. For our usage, we use a male fitting that is the same threading as the tap mechanism (right above). This is fitted to the 3/8″ barb and attached to the other end of the line with the garden hose attachment. We then unscrew our tap assembly using a tap wrench like this one:

IMG_20150111_144559664

With that off, we use the above fitting to attach the tap tower to the pump, and proceed through the steps mentioned above. Apart from the different fittings, the process is essentially identical.

Caveats

In general using a pump is fairly straightforward. Remember, however, that the pump valve is open at all times, and can act as a siphon even when powered off. Be careful of accidentally draining the pump bucket if your lines are hanging down lower than the bucket, in other words.

Also, use the provided handles to lift and move the pump; do not lift it by its electrical cord.

Questions? Make sense?

Books: Fall 2014

To be perfectly honest, I’m terrible at accepting recommendations for books. No idea why, but this is a long term trait. For some reason, however, a bunch of people have asked me about books recently, as they search for new things to read. Given that I had time to cycle through a bunch of books in August and the planes I’ve been on since, here’s a walk through some of the highlights and low lights.

I was not an English major, however, so take the following for whatever it’s worth.

The Good

Angelmaker, Nick Harkaway

12266560

This was a good book. As reviews state, Harkaway occasionally gets a little self-indulgent with his prose (though not nearly so much as in his debut the Gone Away World) and would benefit from a stronger willed editor – his father, perhaps? – but the entire package is original and entertaining. It borrows from the Stephenson tradition of everyman/woman types inadvertently placed in positions of historical significance, but is distinct enough in plot and direction so as to not be derivative.

The Ocean at the End of the Lane, Neil Gaiman

15783514

The third Gaiman book I’ve read, it’s consistent with the others in its ability to seamlessly transit between reality and, for lack of a better term, magic – the kind borrowed from older Celtic traditions, as opposed to more Rowling-esque modernities. Gaiman’s real success here is the perspective; relayed (for the most part) from the viewpoint of a child, it captures the isolated confusion and incomprehensible choices of childhood with ease. It’s a quick read, but worth the time.

The Martian, Andy Weir

18007564

Given the build up around this book, there’s a good chance you’ve heard this story before, but just in case: this is a book that could not find a publisher and ended up being optioned as a movie with Ridley Scott and Matt Damon rumored to be attached. In between, it attracted a cult following because the book is just brilliantly executed. Chronicling the life and times of a stranded astronaut, the technical details were rendered well enough that I assumed the author worked in space flight (he didn’t), but the real highlight of the Martian is its humor. I’d avoid reviews simply because they tend to be a bit spoilerish, but if you’re looking for something to read I’d put this at the top of your list. It’s excellent.

American Gods, Neil Gaiman

4407

Finally got around to this in August, and while the foreward claimed the usual reaction was love or hate, I fell in between. Gaiman’s trademark magic is at work, with a narrative that pits old world traditions against new world addictions. The path meanders at times, but overall the plot moves and its conclusion is worthy of the build up. Still, the serious moral ambiguity of pretty much everyone involved makes it difficult to pick favorites, which leads in my case to a lessened attachment to the work as a whole. Overall though, it’s a tremendously creative book and worth the read.

The Wind-Up Bird Chronicle, Haruki Murakami

11275

There’s a reason that this book sits up near the top of so many top 100 lists: it’s really, really good. The atmosphere is as thick in Wind-Up Bird Chronicle as in VanderMeer’s Southern Reach trilogy, but Murakami answers just enough questions to satisfy the reader, while leaving open huge areas for interpretation. The plot is seemingly simple – where is the protagonist’s wife? – but becomes fractally strange as events move forward. If I had one quibble, it’s that the characters, particularly on the periphery, occasionally lack depth, but some of that undoubtedly is translation. Ultimately, though, that’s a minor point. The overall package is well worth your time.

The Magician’s Land, Lev Grossman

19103097

The conclusion of Grossman’s Magicians trilogy, this brought things full circle for the protagonist of The Magicians. For those that missed the first two books, you can think of them as being set in a cynical, world-weary version of the Harry Potter universe. Magic works, but creates as many problems as it solves for its practitioners. Without giving anything about the plot away, this third book revisits common ground in terms of landscape and the people who occupy it, so if you’re invested in the characters, you’ll like this. And the conclusion is satisfying, if somewhat ambiguous. All in all, a good conclusion to a good series.

Lexicon, Max Barry

16158596

This novel starts off with a bang and in the beginning, you’re likely to be as confused about what’s going on as the first time you watched the Matrix. If you’re patient, however, Barry creates a world that borrows something from the aformentioned Grossman’s Magicians and Stephenson’s Snow Crash. It’s unique, fast-paced and entertaining. The confusion eventually wears off, and what’s left is inventive, often comical and well worth your time even if the ending is a bit neat.

The Meh

One Flew Over the Cuckoo’s Nest, Ken Kesey

332613

I somehow missed this in school, and never saw the movie, but this had less impact than I expected given the book’s reputation. It’s well executed, but it may just be that I’m a square content to be a cog in the machine, because the central theme of rebelling against authority didn’t do much for me. That being said, the bigger picture isn’t necessary to enjoy the story for the cast of characters it introduces and the decisions they make. Not sure I’d recommend it, but it’s worth reading, if only to remember that the World Series was once the big deal.

Mr. Mercedes, Stephen King

18775152

To provide some context for the following comments: I consider myself a Stephen King fan. He was one of my favorite authors growing up, and unlike many of his bestselling counterparts, I believe he takes the craft of writing seriously. He’s not Gabriel Garcia Marquez with the pen, true, but who is? At his best, he’s excellent at capturing place and time, and is always willing to put his characters – good, bad or indifferent – in harm’s way. Oh, and I live in Maine, so naturally I like King. I say all of this because hating on King is fashionable in many literary circles.

All of that said, Mr. Mercedes didn’t do much for me. I’m not among those who say that King’s lost his fastball – I thought Joyland was great – but it had some real issues. First, the characters were borderline cliches: depressed girl, precociously brilliant kid, suicidal ex-cop. Second, the love interest was…not plausible, and that wasn’t the only unlikely behavior. And so on. This wasn’t a bad book, exactly, but it’s certainly not at the top of my list of King novels to read.

The Ugly

Acceptance, Jeff VanderMeer

18077752

Did not enjoy this. Actually, that’s not being honest: I disliked this book intensely. In fact, this book is one of the reasons I bothered to write all of this up in the first place, because the mainstream reviews were – to me, at least – terribly misleading. I didn’t want anyone else to dive into these without a warning.

The intended conclusion of a trilogy about a doomed region known as the Southern Reach, Acceptance cycles us back to characters introduced in the first two novels. Sort of. Probably. Billed variously as Lost meets HP Lovecraft with a dash of Nic Pizzolatto, the one thing I’ll give VanderMeer is that he does atmosphere very well. The first book of the trilogy in particular, Annihilation, is legitimately creepy. The problem is that the rest of the trilogy then completely fails to deliver on the set up. The linked NPR review claims that VanderMeer is:

Trying to tell a story that’s not about knowing and understanding (which is what all books by rational, non-insane people are basically about), but about the impossibility of knowing and the failure of human language and intelligence to encompass something that is completely and totally alien to us.

To me, that’s a cop out. It’s not that every loose end needs to be neatly tied off – see the review for the Wind-Up Bird Chronicle – but I found the complete lack of answers – any answers whatsoever – profoundly disappointing. Selling that as somehow brilliant seems like an excuse after the fact. But even if you accept the above premise, that VanderMeer’s brilliance is about depicting some sort of post-modern unknowability, well, how satisfying is that? Does setting everything up, then saying “well, we can actually never know what any of this is or means” sound like an enjoyable read to you? If so, this is the series for you.

By this third book, I was reading only because I’d invested the time in the first two. Throw in characters not worth investing in and rooting for along with a truly baffling decision to render one entire narrative in the third person, and it was a real slog.

How to Build a French Drain

When we bought our house, it was pretty apparent that the basement had at one time been finished, and at another time subsequent to being finished, seen a lot of water. Though damp basements are far from unusual in Maine, they are less than optimal. Our inspector, eyeing the three or four inch trench dug along one side of the foundation by falling water, thought the culprit might be a lack of gutters. So leading up to our closing, we scheduled a gutter installation. The week before the gutters were installed, we had a massive thunderstorm and a lot of water in the basement. The week after the gutters went in, bigger storm, no water.

Problem solved. We thought.

As it turned out, our gutters work perfectly at keeping our basement dry when the ground isn’t frozen. When the ground is frozen, not so much. Unable to soak into the ground, meltwater from the roof and elsewhere pooled in front of our basement door, then poured through it. Which is why every so often last winter I’d blow up on Twitter about how much I loved hauling a 12 gallon (at 8.34 lbs/gallon) shop-vac full of near freezing water out the door, ten feet away from our foundation to be dumped down a hill. It’s also why my back hurt for most of last winter.

Rather than deal with this for a second winter, we looked at our options and eventually settled on what’s commonly referred to as a French drain (named after a person, not the country), or more specifically a curtain drain which is a fancy way of saying “French drain with a pipe in it.”

The theory behind this is simple: when water pools outside our basement door, we give it somewhere more convenient to go than into our basement – water being, after all, inherently lazy. I say theory because we’re not able to test the drain until a) the ground is frozen and b) we have a lot of water. We can simulate B with a hose, but A is a little harder. We have absolutely no idea if this is going to work, in other words.

In the meantime, however, I thought I’d document the process of creating one for any of you that might have drainage issues. It could also be a useful reminder for myself if this plan fails and I have to dig several more of these when things thaw out in the spring, but I’m trying not to think about that too much.

So, how to build a French Drain.

Step 1

Download this article from Fine Homebuilding (which is an awesome magazine, by the way). Seriously, it’s enormously helpful.

Step 2

1

Get a tractor. You think I’m kidding, but I’m not. Sure, you can dig the ditch yourself, but when was the last time you dug a trench that was two feet deep and twenty or more feet in length? In the heat? Through tree roots, rocks and clay soil? Do yourself a favor and beg, borrow, rent or steal a tractor. We got lucky, as my father-in-law jointly owns one with a friend.

Step 3

2

Start digging your trench. I dug out away from the foundation, and this worked reasonably well. It’s also worth noting that I dug maybe a foot down, then went back and got to the necessary 2′ depth. This was dumb. Dig to the 2′ depth from the start, because going back over a narrow trench with a tractor to dig deeper the second time is a pain in the ass.

Step 4

6

Position your gravel fill (you want 3/4 crushed rock) as close to the trench as possible. Because your back.

Pickup truck sold separately.

Step 5

5

Don’t dig your trench right before a major rainstorm is about to hit. Just trust me on this.

Step 6

7

Get PVC pipe in the appropriate length – I used schedule 40 which is easy to find at Home Depot. Try not to get the flexible plastic kind, unless you want to destroy it when you eventually have to scour out the pipe. Which reminds me, get a sanitary T-connector or similar so that you can blast out the pipe with water easily later. Attached to the head of your pipe, you can dig it up later and snake your drainage pipe if it gets clogged.

The other thing you need to do – unless you can find PVC that’s pre-drilled – is put a bunch of holes in one side of it. I used a 1/4″ or 3/8″ drillbit, I think. I never did find a conclusive answer on how many holes were required, but I probably put in half a dozen per six to eight inches. Enough to allow water entry, but not weaken the pipe.

PVC Protip: deal with PVC cement as little as possible, and do not – under any circumstances – open it indoors.

Step 7

8

With your trench dug, it’s time to get the trench liner ready; I used this stuff. Basically the purpose of this is to keep as much sediment out of the crushed rock and PVC pipe as possible.

Step 8

9

Use your tractor to lay down an inch or two of crushed rock, then position the PVC pipe slanted away from your foundation. Point the holes downward. You need a drop of 1/8″ per linear foot, apparently. And no, I have no idea how you’re supposed to measure that if you’re not a surveyor. I just made sure it slanted down, hard.

Articles like the Fine Homebuilding one will tell you to use the gravel to adjust the pitch appropriately, and that’s what you have to do, but it’s a pain in the ass. Just FYI.

Step 9

10

Cement pipe segments together as necessary. If you thought adjusting the pitch of one segment was a bitch, wait until you try it with two. Also, PVC cement sucks.

Step 10

13

Once you have the pitch correct, begin backfilling the trench with crushed rock. Don’t drop in too much at a time because you’ll mess up the pitch, or if you were dumb and didn’t go with the rigid PVC, you’ll damage the pipe. Once you’re near the top, you can begin folding the fabric over. If you’re an idiot and you dug one section of the trench too wide like I did and you’re short on fabric, just find something heavy to hold the fabric in place. Cinderblock, the giant fucking rocks the goddammned tractor refused to pull up so you had to dig out by hand, whatever.

Step 11

15

Once you’ve filled the trench, and sealed the top by folding over the typar fabric, you can begin covering everything up with topsoil. Tamp it down tightly or it will all wash away with the first good rain that you get. Or so I’ve heard. I used one of these.

Step 12

17

Unless you enjoy the Frankenstein-like scar on your lawn, you might want to plant some grass seed when you’re done. Sadly, Scott’s made the terrible decision to no longer sell Fenway grass seed. We used this instead, and while it’s a completely different shade of green from the rest of our lawn, at least we have grass there now.

Step 13

In our case at least, Step 13 is to pray. This project cost us a couple of hundred bucks, several weekends of effort and some blood – though admittedly much less than in our “get rid of closet debris” debacle that landed me in the hospital. In spite of all of that, we have no idea if it’s actually going to work or not.

If it doesn’t, I’m sure I’ll have some equally harebrained scheme to share with you next winter. In the meantime, hope this helps.
